Esser 808631.10 RZT 12 V Conventional Zone Transponder (4 Zones)
Product Code: 808631.10
This model is the 12 V DC version of the zone transponder that transfers four conventional zone inputs to addressable addressing; zone voltage is fixed and non-adjustable. It is preferred in renovation work where the wiring of old detectors and buttons is preserved and the system power supply is 12 V. It offers two relay outputs for general-purpose control. Since it matches the panel power supply, it can be put into service without installing an additional voltage converter.
Dealer priceSign in as a dealer for price and stock →
Technical specifications
| Architecture | Adresli |
| Protocol | esserbus |
| Operating Voltage | 10,5 … 13,8 V DC |
| Operating Temperature | -10 °C … +50 °C |
