Products / Fire Detection Systems / Detnov / Detnov MAD-481 240 Vac 5A Dry Contact Output Addressed Relay Module
Detnov
Detnov MAD-481 240 Vac 5A Dry Contact Output Addressed Relay Module
Product Code: MAD-481
A single dry contact relay module controlled from the addressed loop. With C, NO, NC contacts switching 240 Vac and 5A, it enables operation of external installations such as elevators, ventilation, and doors in fire scenarios; the contact does not automatically reset. It receives a single address from the loop, requires 24 Vdc auxiliary power supply, and can be connected regardless of polarity.
Dealer priceSign in as a dealer for price and stock →
Technical specifications
| Architecture | Adresli |
